Climb every bad road challenge
Climate control
Sleeping
place
place
Cruise
control
control
LCD Display
Electric
window lifts
window lifts
Bluetooth + USB
Remote control
Air suspension
seat
seat
Options
- Wheel formula: 4x2
- Overall dimensions, mm: 6 150 х 2 500 х 3850
- Fuel tank capacity, l: 600
- Gross vehicle weight, kg: 18 000
- Gross semi-trailer weight, kg: 34 870
- Gross train weight, kg: 42 000
- Permissible load (front axle/rear axle), kg: 6 500/11 500
- Load on SSU, kg: 10 870
- Curb weight of the car, kg: 7 130
- Tires: 12R22.5-18PR
- Brake system: Double-circuit pneumatic
- Steering: TRW
- Model: Weichai WP10H400E50 (Diesel)
- Power, hp: 400
- Torque, rpm: 1900
- Number of cylinders: 6
- Working volume, l: 9.5
- Environmental class level: Euro-5
- Gearbox: C12JSDQXL200TA
- Number of gears: 12
- Clutch: F430, flap wringer
- Front suspension: Dependent, leaf-spring
- Rear suspension: Dependent, air -cushion
- Maximum speed, km/h: 120
- The maximum slope of the rise,%: 40
- Ground clearance, mm: 222
- Wheel formula: 4x2
- Overall dimensions, mm: 6 150 х 2 500 х 3850
- Fuel tank capacity, l: 600
- Gross vehicle weight, kg: 18 000
- Gross semi-trailer weight, kg: 34 870
- Gross train weight, kg: 42 000
- Permissible load (front axle/rear axle), kg: 6 500/11 500
- Load on SSU, kg: 10 870
- Curb weight of the car, kg: 7 130
- Tires: 12R22.5-18PR
- Brake system: Double-circuit pneumatic
- Steering: TRW
- Model: Weichai WP10H400E50 (Diesel)
- Power, hp: 400
- Torque, rpm: 1900
- Number of cylinders: 6
- Working volume, l: 9.5
- Environmental class level: Euro-5
- Gearbox: C12JSDQXL200TA
- Number of gears: 12
- Clutch: F430, flap wringer
- Front suspension: Dependent, leaf-spring
- Rear suspension: Dependent, air -cushion
- Maximum speed, km/h: 120
- The maximum slope of the rise,%: 40
- Ground clearance, mm: 222
